Cinema & broadcast / CAMERA REFERENCE

ALEXA Mini LF

ARRI

Announced: 28 March 2019

Announced 28 March 2019; ARRI later confirmed production shipments beginning 18 September 2019.

The Mini LF combined ARRI’s large-format sensor with a body sized for compact rigs. Internal ND filters and Codex Compact Drives were part of the design; the viewfinder remained a separate component.

01 / TECHNICAL RECORD

Specifications

Manufacturer technical data as accessed; recording modes may include later firmware additions. Source: ARRI technical data ↗.

Sensor and recording

Sensor: Large-format ALEV III; 4448 x 3096; 36.70 x 25.54mm
Open-gate recording: 4.5K 3:2 up to 40 fps
Recording formats: ARRIRAW; ProRes 4444 XQ, 4444 or 422 HQ

Operation and workflow

Media: Codex Compact Drives
Filters: Motorised FSND: clear, 0.6, 1.2, 1.8
Viewfinder: MVF-2 with 4-inch flip-out monitor
Weight: About 2.6kg with LPL mount

02 / INDEPENDENT COVERAGE

Reviews and field reports

Independent coverage

CineD · ALEXA Classic and Mini LF lab test ↗

Machu measured 13.5 stops at SNR=2 in ProRes 4444 XQ at ISO 800 and 13.4 in ARRIRAW. His studio test found about ten stops of exposure latitude, with noise reduction needed for the deepest recovered shadows. These are results from the tested modes, rather than a general rating of every recording format.

Gunther Machu · CineD

03 / PROVENANCE

Sources and dates

A catalogue year identifies the year held in the source dataset. Announcement dates and retail months are labelled separately. Specifications can vary by region, firmware and recording mode; use the linked manufacturer documentation for those conditions.

Archive updated 2026-10-04. Archive coverage and dataset credits →
